Description
THE THIRD GENERATION AVIATION ALUMINUM GANTRY
It is manufactured with aerospace standards and formed by 4300 tons press extrusion molding. After aging treatment, its strength can reach 6061 T6 which is the strongest strength of all gantries. Aviation aluminum has many advantages, such as good toughness, light weight, corrosion resistance, anti-oxidation, low density, and greatly increase the processing speed
Technical Parameters
Machine model
LF4020GH
LF6025GH
LF10025GH
LF12025GH
Laser power
8000W 12000W 15000W 20000W(Optional)
Dimensions
11475*2574*5169mm
14937*3952*2287mm
22953.5*4006*2336.5mm
27092*4119*2336.5mm
Working area
4000mm*2000mm
6000mm*2500mm
10000mm*2500mm
12000mm*2500mm
Repeat positioning accuracy
±0.02mm
Maximum speed
200m/min
Max. acceleration
2.5G
Voltage and frequency
380V 50Hz/60HZ
