Description
THE THIRD GENERATION AVIATION ALUMINUM GANTRY
It is manufactured with aerospace standards and formed by 4300 tons press extrusion molding. After aging treatment, its strength can reach 6061 T6 which is the strongest strength of all gantries. Aviation aluminum has many advantages, such as good toughness, light weight, corrosion resistance, anti-oxidation, low density, and greatly increase the processing speed.
Technical Parameters
Machine model
LF1390
Laser power
500W 750W 1000W(Optional)
Working area
1300mmx900mm
Repeat positioning accuracy
±0.008mm
Maximum speed
40m/min
Maximum acceleration
0.5G
Transmission mode
Grinding precision screw drive
Specified voltage and frequency
220V/50Hz/60Hz/60A
