Description
THE THIRD GENERATION AVIATION ALUMINUM GANTRY
It is manufactured with aerospace standards and formed by 4300 tons press extrusion molding. After aging treatment, its strength can reach 6061 T6 which is the strongest strength of all gantries. Aviation aluminum has many advantages, such as good toughness, light weight, corrosion resistance, anti-oxidation, low density, and greatly increase the processing speed.
Technical Parameters
Machine model
LF3015GA
LF4020GA
LF6025GA
Laser power
1000W 2000W 3000W 4000W 6000W(Optional)
Dimensions
8150*2825*2125mm
10750*3350*2310mm
15000*4018*2755mm
Working area
3000mm*1500mm
4000mm*2000mm
6000mm*2500mm
Repeat positioning accuracy
±0.02mm
Maximum speed
120m/min
Max. acceleration
1.5G
Voltage and frequency
380V 50Hz/60HZ
